Chicago (CH1-Lisle) Data Center

Address 4513 Western Ave, Lisle, Illinois, USA Space
Open Time Power
Owner Evoque Data Center Solutions Air conditioning & Cooling
Contact +1 877-866-6190 ,N/A Standards
Data Center Introduction

Evoque Data Center Solutions: Chicago (CH1-Lisle) Data Center

Evoque Data Center Solutions Chicago (CH1-Lisle) Data Center is located at 4513 Western Ave, Lisle, Illinois, USA. The data center is 190057 sqft. There is a total of 99650 sqft in raised floor space for colocation. No power information has been offered for this location. We found 82 data center locations within 50 miles of this facility. Certifications for this location include HIPAA, HITECH, PCI-DSS, SSAE-16 Type 1, SOC 2 Type 2, ISO 27001, FISMA, SOC 1, SOC 2, SOC 3, SOC 2 Type 1, SSAE-16 Type 2, FedRAMP, SOC 1 Type 2, NIST 800-53.

Data Center Overall: 194,057 sq. ft.

Colocation: 99,650 sq. ft.

Office Space: Customer drop in cubicles

Site Area: Low rise, industrial

Seismic Zone: 1

Built: 1972 Retrofitted: 2000

Types: Cage, locking cabinets Standard Rack: 42U Raised Floor Load: 150 lbs. / sq. ft. Sub Floor Load: 300 lbs. / sq. ft. Cross Connect: Copper, fiber, coaxial Remote Hands: 24x7 Loading Dock: Yes

Electrical Capacity Phase 1: 120 w/sq. ft. Phase 2: 150 w/sq. ft. Cabinet (2.4, 4.3 & 6.2 Kw) UPS Configuration: 2N # Utility Feeders: 4 Standby Power Config: N+1

HVAC Distribution: N+1 HVAC System: N+1 Chillers: Six 500 ton chiller/cooling towers with two 20,000 gallons on site water

Fire Alarm: VESDA smoke detection and conventional addressable fire alarm system Fire Suppression Data Center Areas: Pre-action dry pipe Non-Equipment Areas: Wet sprinkler
