Dallas (DA2-Webb Chapel) Data Center

Address 11830 Webb Chapel Rd, Dallas, TX, USA Space
Open Time Power
Owner Evoque Data Center Solutions Air conditioning & Cooling
Contact +1 877-866-6190 ,N/A Standards
Data Center Introduction

Evoque Data Center Solutions: Dallas (DA2-Webb Chapel) Data Center

Evoque Data Center Solutions Dallas (DA2-Webb Chapel) Data Center is located at 11830 Webb Chapel Rd, Dallas, TX, USA. The data center is 140453 sqft. There is a total of 92320 sqft in raised floor space for colocation. No power information has been offered for this location. We found 88 data center locations within 50 miles of this facility. Certifications for this location include HIPAA, HITECH, PCI-DSS, SSAE-16 Type 1, SOC 2 Type 2, ISO 27001, FISMA, SOC 1, SOC 2, SOC 3, SOC 2 Type 1, SSAE-16 Type 2, FedRAMP, SOC 1 Type 2, NIST 800-53.

Data Center Overall: 140,654 sq. ft.

Colocation: 92,320 sq. ft.

Office Space: Customer drop in cubicles

Site Area: Business park

Seismic Zone: 1

Built: 2000 Retrofitted: 2008 & 2018

Types: Cage, locking cabinets Standard Rack: 42U & 51U Raised Floor Load: 300 lbs. / sq. ft. Sub Floor Load: 300 lbs. / sq. ft.

Cross Connect: Copper, fiber, coaxial Remote Hands: 24x7

Electrical Capacity Phase I & II - 120 w/sq. ft. Phase III & IV - 200 w/sq. ft. Cabinet (2.4, 4.3 & 6.2 Kw) UPS Configuration: N+1 # Utility Feeders: 2 Standby Power Config: N+1 Standby Power: Six 2,000 Kw diesel generators, five belly tanks and one standalone.

HVAC Distribution: N+1 HVAC System: N+1 Chillers: Eight 400 ton air-cooled chillers. Closed chill water loop with municipal makeup water.

Fire Alarm: VESDA smoke detection and conventional addressable fire alarm system Fire Suppression Data Center Areas: Pre-action dry pipe Non-Equipment Areas: Dry pipe
